Casio Nozzles

casio nozzle

Dobeter supply a wide range of Casio nozzles, these Casio Nozzles are precision-engineered components designed to ensure accurate and reliable placement of electronic parts, enhancing efficiency and quality in Casio surface mount pick-and-place machines.
Casio nozzles are crafted for high precision and durability, tailored to the specifications of Casio SMT pick-and-place machines uch as Casio YCM-7000/ 7700 / 7800/ 8800, YCM-3300, YCM-3500 Casio 7000 and so on.. These Casio Nozzles ensure reliable component pick-up and placement, reducing errors and downtime in fast-paced manufacturing environments. They come in various sizes and shapes to accommodate different component types, promoting versatility across industries such as consumer electronics and telecommunications.
Types and Materials of SMT Nozzles
Nozzles vary by shape and material to match component and assembly requirements:
– Round nozzles: Commonly used for small components like resistors and capacitors.
– Square nozzles: Suited for ICs and square components, providing stable grip.
– Needle nozzles: Thin tips allow access in tight spaces for dense PCB layouts.
– V-shaped nozzles: Designed for angled components or connectors.
– Common materials include tungsten steel, ceramic, diamond steel, and rubber heads. Tungsten steel offers durability but may show white discoloration over time; ceramic nozzles resist discoloration but require careful handling; diamond steel nozzles are highly durable but costly; rubber heads are for sticky or uneven components .
Casio SMT nozzles are designed to fit a range of Casio SMT machines, with nozzle sizes selected based on component dimensions. For example, nozzle numbers correspond to minimum component widths or diameters. Choosing the right nozzle depends on component shape, size, and height, with the aim to optimize placement accuracy by matching nozzle aperture to component profile.
Dobeter also supply custom nozzles may be needed for irregular or non-standard components.
