Fuji NXT H24 Nozzles

Dobeter’s Fuji NXT H24 nozzles come in various sizes and types made primarily from durable ceramic, designed for precise and reliable component placement on SMT pick-and-place machines, compatible with Fuji AIM, AIMEX, and NXT series heads.
Dobeter’s Fuji NXT H24 nozzles are manufactured in a variety of diameters, typically ranging from 0.19mm up to 2.5mm, including common sizes such as 0.3mm, 0.35mm, 0.4mm, 0.5mm, 0.7mm, 0.8mm, 1.0mm, 1.3mm, 1.8mm, and 2.5mm. These Fuji NXT H24 nozzles include standard assemblies, as well as options such as wide range nozzles and specialized MELF nozzles for specific component shapes and sizes.
Dobeter’s Fuji NXT H24 nozzles are made from high-grade ceramic materials, ensuring durability, precision, and resistance to wear over extended production runs. Some models use conformable designs for better handling of irregular component shapes .These nozzles are designed for use on Fuji AIM, AIMEX, and NXT pick-and-place machines equipped with H24 heads, enabling seamless integration with existing Fuji SMT setups.
Fuji NXT H24 nozzles are engineered for precise component pickup and placement, minimizing downtime and maximizing throughput in SMT manufacturing. They are suitable for various components, ranging from very small to larger-sized parts requiring more extensive nozzles.

In essence, Fuji NXT H24 nozzles are a critical consumable for SMT production lines equipped with Fuji machines, offering highly precise and durable solutions across a broad size range and compatible with multiple machine models to meet various assembly requirements. Ensuring you choose the correct nozzle size and type is key for optimal placement accuracy and machine performance.
If you need a specific nozzle part or custom advice, contacting Dobeter with details of your machine model and component types is recommended.

Common Fuji NXT H24 nozzles types and part numbers
FUJI NXT Nozzle Head H24 ø0.2 NXT, R047-002-035 2AGKNX005100
FUJI NXT Nozzle Head H24 ø0.3 NXT, R047-003-035 2AGKNX005200
FUJI NXT Nozzle Head H24 ø0.35 NXT 2AGKNX005300
FUJI NXT Nozzle Head H24 ø0.4 NXT, R047-004-035 2AGKNX005400
FUJI NXT Nozzle Head H24 ø0.5 NXT, R047-005-035 2AGKNX005500
FUJI NXT Nozzle Head H24 ø0.6 NXT wide range S, R047-006WRS-035 2AGKNX007500
FUJI NXT Nozzle Head H24 ø0.7 NXT, R047-007-035 2AGKNX003100
FUJI NXT Nozzle Head H24 ø0.8 NXT, R047-008-035 2AGKNX006300
FUJI NXT Nozzle Head H24 ø1.0 NXT, R047-010-035 2AGKNX003500
FUJI NXT Nozzle Head H24 ø1.1 NXT wide range M, R047-011WRM-035 2AGKNX007600
FUJI NXT Nozzle Head H24 ø1.3 NXT, R047-013-035 2AGKNX001700
FUJI NXT Nozzle Head H24 ø1.3 Melf NXT, R047-013M-035 2AGKNX004000
FUJI NXT Nozzle Head H24 ø1.8 NXT, R047-018-035 2AGKNX003700
FUJI NXT Nozzle Head H24 ø1.8 Melf NXT, R047-018M-035 2AGKNX004100
FUJI NXT Nozzle Head H24 ø1.8 NXT wide range L, R047-018WRL-035 2AGKNX007700
FUJI NXT Nozzle Head H24 ø2.5 NXT, R047-025-035 2AGKNX003900
FUJI NXT Nozzle Head H24 ø2.5G NXT, with Rubber Pad, R047-025G-035 2AGKNX001400
FUJI NXT Nozzle Head H24 ø2.5 Melf NXT, R047-025M-035 2AGKNX004200
