JUKI Nozzles

JUKI is a prominent manufacturer in the Surface Mount Technology (SMT) industry, we offer a comprehensive range of JUKI nozzles designed to enhance the precision and efficiency of their pick-and-place machines. These nozzles are integral to the accurate placement of electronic components onto printed circuit boards (PCBs) during assembly processes. Dobeter’s JUKI nozzles are precision-engineered components essential for reliable and accurate component placement in SMT assembly lines, offering a wide range of nozzle types to accommodate various component sizes and shapes while ensuring high durability and compatibility with JUKI pick-and-place machines..
Nozzle Types and Specifications
JUKI offers an extensive range of nozzles tailored for different component sizes and complexities:
– Small component nozzles, like the Juki Nozzle 501, are ideal for tiny parts ranging from 0201 to 0603 sizes.
– Medium-sized component nozzles, such as the 503 or 504 models, handle parts between 0805 and 1812 sizes with precision and stable placement.
– Large and heavy-duty nozzles, including the Juki Nozzle 505 and 508, are designed for larger or irregularly shaped parts, providing strong vacuum grip and robust construction.
– Fine pitch and specialized nozzles, like the 506 and 507, cater to delicate microchips (QFPs, BGAs) or odd-shaped components, minimizing risks of damage during placement.
We offer you JUKI’s standard nozzle series caters to a variety of component sizes and types: 500, 501, 502, 503, 504, 505… For components that present unique handling challenges, we provides JUKI specialized nozzle such as Custom Nozzles solutions tailored to specific requirements, SMT Gripper Nozzles which mechanically grip the component to ensure accurate placement. Using Dobeter’s JUKI nozzles can enhances SMT assembly line performance by ensuring reliable, efficient, and accurate placement, which is vital for maintaining product quality and manufacturing productivity in modern electronics industries

JUKI nozzle part number and description :
E35017210A0 JUKI NOZZLE 101 ASSY Ø 1.0×0.4
E35027210A0 JUKI NOZZLE 102 ASSY Ø 1.5×1.0
E35037210A0 JUKI NOZZLE 103 ASSY Ø3.0×1.7
E35047210A0 JUKI NOZZLE 104 ASSY Ø 4.0×3.2
E35057210A0 JUKI NOZZLE 105 ASSY Ø 6.5×5.0
E35067210A0 JUKI NOZZLE 106 ASSY Ø 9.0×8.0
E35517210A0 JUKI NOZZLE 201 ASSY Ø 3.5×1.0
E35527210A0 JUKI NOZZLE 202 ASSY Ø 5.5×3.2
E35537210A0 JUKI NOZZLE 203 ASSY Ø 8.5×5.0
E35547210A0 JUKI NOZZLE 204 ASSY Ø 9.0×8.0
E36087290A0/40011046 JUKI NOZZLE 500 ASSY Ø1.0 X 0.5
E36007290A0/40001339 JUKI NOZZLE 501 ASSY Ø 0.7×0.4
E36017290A0/40001340 JUKI NOZZLE 502 ASSY Ø 0.7×0.4
E36027290A0/40001341 JUKI NOZZLE 503 ASSY Ø1.0×0.6
E36037290A0/40001342 JUKI NOZZLE 504 ASSY Ø1.5/1.0
E36047290A0/40001343 JUKI NOZZLE 505 ASSY 3.5/1.7
E36057290A0/40001344 JUKI NOZZLE 506 ASSY Ø5.0/3.2
E36067290A0/40001345 JUKI NOZZLE 507 ASSY Ø8.5/5.0
E36077290A0/40001346 JUKI NOZZLE 508 ASSY Ø8.5 /5.0
E36077290A0/40025165 JUKI NOZZLE 509 ASSY Ø0.1/0.4
E36157290A0 JUKI NOZZLE 510 ASSY Ø1.5/0.6
E36167290A0 JUKI NOZZLE 511 ASSY Ø2.0/1.2
E40017210A0 JUKI PICK UP NOZZLE
E40027210A0 JUKI PICK UP NOZZLE
E40057210A0 JUKI PICK UP NOZZLE
E40067210A0 JUKI PICK UP NOZZLE
E40077210A0 JUKI PICK UP NOZZLE
E40087210A0 JUKI PICK UP NOZZLE
E40097210A0 JUKI PICK UP NOZZLE
E40107210A0 JUKI PICK UP NOZZLE
E40117210A0 JUKI PICK UP NOZZLE
E40127210A0 JUKI PICK UP NOZZLE
E40137210A0 JUKI PICK UP NOZZLE
E40147210A0 JUKI PICK UP NOZZLE
E40167210A0 JUKI PICK UP NOZZLE
E40177210A0 JUKI PICK UP NOZZLE
E40187210A0 JUKI PICK UP NOZZLE
E40207210A0 JUKI PICK UP NOZZLE
E40217210A0 JUKI PICK UP NOZZLE
E40227210A0 JUKI PICK UP NOZZLE
E40237210A0 JUKI PICK UP NOZZLE
E40247210A0 JUKI PICK UP NOZZLE
E40257210A0 JUKI PICK UP NOZZLE
