Suzuki SMT Nozzles

Suzuki manufactures pick-and-place nozzles for its line of surface mount technology (SMT) machines, which are used to assemble electronic circuit boards

. These precision Suzuki SMT Nozzles are essential for accurately picking up components and placing them onto a printed circuit board (PCB).

Suzuki SMT Nozzles types

Suzuki SMT nozzles come in various styles and sizes, with specific part numbers corresponding to different machine models and component requirements.

R series nozzles

The “R” series of nozzles is designed for specific component handling, with common types including:

• R1 nozzle: For components with a diameter of 1.2mm or 1.85mm.
• R2 nozzle: For components with a diameter of 3.0mm.
• R3 nozzle: Handles components with diameters of 4.0mm and 3.0mm.
• R4 nozzle: For components with diameters of 3.0mm and 1.0mm.

C series nozzles

The “C” series nozzles are designed for other component types, such as square or rectangular chips:

• C1 nozzle: For components measuring 1.2mm by 1.5mm.
• C13 nozzle: For components measuring 1.3mm by 1.35mm.
• C15 nozzle: For components with a diameter of 2.2mm.

Suzuki SMT Nozzlesfor specific Suzuki machines

Nozzles are also available for older or specialized Suzuki SMT machine models, including:

• 1000 and 2500 series
• 2350 and 2300C series
• 2300H and 2500H series
• 1150 and 1160 series
• 2000-V series
