Yamaha Nozzle YG12 YG12F YS12 YS12F YSM10 YSM20 YS24 YS24X YG300

Dobeter supply a variety of Yamaha Nozzle for YG12 YG12F YS12 YS12F YSM10 YSM20 YS24 YS24X YG300 , such as 301A, 302A, 303A, and others are designed for Yamaha pick and place SMT machines including YG12, YG12F, YS12, YS12F, YSM10, YSM20, YS24, YS24X, and YG3. These nozzles support precise component placement and are available from multiple suppliers with options for custom manufacturing and fast delivery. These nozzles support various component sizes and types for surface mount technology (SMT) assembly lines. Dobeter also make custom nozzles which can be manufactured for special parts such as micro components (e.g., 0201, 01005 sizes), LEDs from brands like Cree and Lumileds, connectors, push buttons, and heavy or oversized components upon request . Nozzle holders, shafts, ball splines, and dummy nozzles (used for calibrating the nozzle rotational axis) are also available for these models to maintain operational precision.
For Yamaha SMT pick and place machines such as the YG12 series, YS12 series, and YS24 series, an extensive variety of nozzles and related parts are available. These nozzles ensure precise placement of various component sizes and types on PCBs. Suppliers also provide customization services for specialized needs, alongside essential accessories like nozzle holders and dummy jigs for calibration and maintenance.
If you need specific part numbers or custom solutions, it is recommended to contact specialized suppliers who can offer details, samples, and technical assistance based on your requirements.
This ensures optimal machine performance and consistent production quality for your SMT assembly processes.

Below is a list of Yamaha Nozzle for YG12 YG12F YS12 YS12F YSM10 YSM20 YS24 YS24X YG300
Part No. Part Name Q’ty Remarks
KHN-M7710-A1 NOZZLE 301A ASSY. 1 TYPE 301A
KHN-M7710-A2 NOZZLE 301A ASSY. 1 TYPE 301A
KHN-M7710-A3 NOZZLE 301A ASSY. 1 TYPE 301A
KHN-M7711-01 BODY,NOZZLE 1 1
KHN-M7711-02 BODY,NOZZLE 301 1
KHN-M7711-03 BODY,NOZZLE 301 1
KHN-M7711-04 BODY,NOZZLE 301 1

KHN-M7713-00 SPRING 1
KHN-M7714-00 PIN 1
KHN-M7715-00 CLIP 1
KHN-M7720-A1 NOZZLE 302A ASSY. 1 TYPE 302A
KHN-M7720-A2 NOZZLE 302A ASSY. 1 TYPE 302A
KHN-M7721-01 BODY,NOZZLE 2 1
KHN-M7721-02 BODY,NOZZLE 302 1
KHN-M7721-03 BODY, NOZZLE 302 1

KHY-M7740-A0 NOZZLE 303A/314A ASSY. 1 TYPE 303A/314A
KHY-M7741-00 BODY,NOZZLE 303/314 1

KHY-M7750-A0 NOZZLE 304A/315A ASSY. 1 TYPE 304A/315A

90990-17J013 O-RING 5
KHY-M7770-A0 NOZZLE 306A/317A ASSY. 1 TYPE 306A/317A
KHY-M7771-00 BODY,NOZZLE 306/317 1

KHY-M77A0-A0 NOZZLE 310A ASSY. 1 TYPE 310A (Narrow adjacent Type)
KHY-M77A1-00 BODY,NOZZLE 310 1

KHY-M7710-A0 NOZZLE 311A ASSY. 1 TYPE 311A(Narrow adjacent Type)
KHY-M7710-A1 NOZZLE 311A ASSY. 1 TYPE 311A
KHY-M7710-A2 NOZZLE 311A ASSY. 1
KHY-M7710-A3 NOZZLE 311A ASSY. 1 TYPE 311A (Narrow adjacent Type)
KHY-M7711-00 BODY,NOZZLE 311 1
KHY-M7711-01 BODY,NOZZLE 311 1
KHY-M7711-02 BODY, NOZZLE 311 1
KHN-M7713-10 SPRING 1
KHY-M7720-A0 NOZZLE 312A ASSY. 1 TYPE 312A (Narrow adjacent Type)
KHY-M7720-A1 NOZZLE 312A ASSY. 1 TYPE 312A (Narrow adjacent Type)
KHY-M7720-A2 NOZZLE 312A ASSY. 1 TYPE 312A (Narrow adjacent Type)
KHY-M7721-00 BODY,NOZZLE 312 1
KHY-M7721-01 BODY,NOZZLE 312 1

KHY-M7730-A0 NOZZLE 313A ASSY. 1 TYPE 313A (Narrow adjacent Type)
KHY-M7730-A1 NOZZLE 313A ASSY. 1 TYPE 313A (Narrow adjacent Type)
KHY-M7731-00 BODY,NOZZLE 313 1
KHY-M7731-01 BODY,NOZZLE 313 1
