Panasonic SMT Spare Parts

Dobeter supply a wide range of Panasonic SMT spare parts, these Panasonic SMT spare parts include key components like placement heads, nozzles, feeders, motors, sensors, and control boards that ensure high-precision and reliable operation of NPM, CM, and AM series machines.

The placement head is the core of a pick-and-place machine, responsible for precise component placement on PCBs. Essential components include:
– Ball-splines and rails for smooth motion (e.g., N510005433AA, N510015533AA).
– Motors controlling accurate movement (e.g., MTNM000004AA, N510043454AA).
– PCB control boards that manage data and synchronization (e.g., KXFE0004A00, N610102225AA) .
– Packing, O-rings, regulators, and valves to maintain pressure and positioning accuracy (e.g., KXF05YHAA00, KXF0DLLAA01).
– Sensors for detection and alignment (e.g., MTNS000240AA, N510058203AA).
– Belts, pulleys, housing, and plates that provide structural support and durability (e.g., N510021326AA, MTKA005213AB) .

Nozzles
SMT nozzles hold and place electronic components precisely. Key considerations for replacement or selection include compatibility with the machine type (NPM-W2, CM602) and component size:
– 16- or 12-nozzle head models (e.g., N210007281AD, N610017370AC)
– 8-nozzle head models (e.g., N610040784AD, N610062681AA)
– 2- or 3-nozzle head models (e.g., KXFX037SA00, MTNP002974AA)

Feeder Parts
Feeder parts ensure smooth delivery of components from reels to the placement area. Essential feeder components include:
– Reels, rollers, pins, collars, stoppers, nuts, and diagonal guide sets
– Feeder mechanisms for 8mm, 12mm, 16mm, 24mm, and 32mm tape widths
– Each part ensures precision, avoids jams, and supports uninterrupted production .

Other Key Spare Parts
Panasonic SMT machines also require spare parts such as:
– Power supplies and fans (e.g., KXFP6EM4A00) .
– Communication cables and connection boards (e.g., N510026292AA, MTKC010710AA).
– Gears, stops, pins, air cylinders, valves, and sensors (e.g., N210050454AA, KXF0DXESA00).
– Adjustment jigs, belts, and levers for maintenance and reliable placement.

Using Dobeter’s Panasonic SMT spare parts ensures high-speed, high-accuracy assembly, reduces production interruptions, and extends the operational life of Panasonic SMT machines.
