Hanwha feeder loading unit—also known as the feeder loading jig or offline feeder preparation unit is a standalone tool used to prepare and configure Hanwha SMT feeders (SM and SME types) outside the main machine. Hanwha feeder loading unit allows you to load and position tapes precisely， calibrate the feeder’s internal mechanism for correct pitch and eject pin alignment， simulate feeder operation offline before machine installation， Hanwha feeder loading unit is designed for SM (pneumatic) and SME (electric) feeders across all tape widths: 8 mm, 12 mm, 16 mm, 24 mm, 32 mm, 44 mm, 56 mm, and up to 72 mm, Enables setup and diagnostics of feeders for SMT machines such as SM410 series, SM321/421/471/481/482, CP Series, and Decan/Excen platforms.
Offline setup: Feeders can be prepared with tape and settings before being mounted in the machine.
Test mode simulation: Allows operators to ensure accurate tape feeding and pocket alignment.
Hanwha feeder loading unit minimizes machine downtime during model changeovers or feeder maintenance.
